Description
Robertshaw 700-506 Gas Valve, Fast Opening, 300,000 BTUH
The Robertshaw 700-506 Gas Valve is a fast-opening millivolt gas control valve designed for compatible natural gas heating equipment. With a 300,000 BTUH capacity, 3/4" FPT inlet and outlet connections, and factory-set natural gas pressure regulation, this Robertshaw 700 Series gas valve is a dependable replacement option for professional HVAC and gas appliance service applications.
Call: 256-432-7622
Key Features
- Robertshaw 700 Series gas valve
- Model number: 700-506
- Fast-opening valve operation
- 300,000 BTUH capacity
- Designed for natural gas applications
- Can be converted to LP propane with the proper Robertshaw conversion kit
- Recommended LP conversion kit: Robertshaw 1751-013
- Millivolt control operation
- 3/4" FPT inlet connection
- 3/4" FPT outlet connection
- Straight-through gas flow configuration
- Factory-set natural gas pressure regulation
- Suitable for professional HVAC replacement applications
Product Specifications
| Product Name | Robertshaw 700-506 Gas Valve |
|---|---|
| Model Number | 700-506 |
| Factory Model | 7000BMVR |
| Brand | Robertshaw |
| Product Type | Gas Valve |
| Valve Opening | Fast Opening |
| Fuel Type | Natural Gas; convertible to LP propane where approved |
| BTUH Capacity | 300,000 BTUH |
| Natural Gas Pressure Regulation | 3.5" W.C. |
| LP Conversion Kit Reference | Robertshaw 1751-013 |
| LP Regulator Setting | Approximately 11" W.C. when properly converted and adjusted |
| Electrical Rating | 250mV to 750mV |
| Inlet Size | 3/4" FPT |
| Outlet Size | 3/4" FPT |
| Outlet Configuration | Straight-Thru |
| Maximum Inlet Pressure | 14" W.C. / 1/2 PSI |
| Ambient Temperature Range | -40°F to 175°F |
Natural Gas to LP Propane Conversion
The Robertshaw 700-506 Gas Valve is designed for natural gas applications but may be converted for use with LP propane when used with the proper manufacturer-approved conversion kit and when the connected appliance is also approved and properly converted for propane operation.
For compatible Robertshaw 700 Series gas valves, the recommended LP conversion regulator kit is Robertshaw Part Number 1751-013. This kit is commonly used to convert compatible Robertshaw 700 Series valves from natural gas to LP propane.
Applications
The Robertshaw 700-506 gas valve is designed for compatible natural gas heating equipment that requires a fast-opening millivolt gas control valve. It may be used in select furnaces, unit heaters, commercial heating equipment, and other approved gas-fired appliances where the specifications match the appliance requirements.
Frequently Asked Questions
What is the Robertshaw 700-506 gas valve used for?
The Robertshaw 700-506 is used as a replacement gas valve for compatible gas-fired heating equipment that uses a millivolt control system.
What is the BTUH capacity of the Robertshaw 700-506?
This product page lists the Robertshaw 700-506 gas valve with a 300,000 BTUH capacity.
Can the Robertshaw 700-506 be converted to LP propane?
Yes. Compatible Robertshaw 700 Series valves may be converted from natural gas to LP propane using the appropriate manufacturer-approved LP conversion kit when the appliance manufacturer permits conversion.
What LP conversion kit is used for the Robertshaw 700-506?
The reference LP conversion kit is Robertshaw 1751-013 for compatible Robertshaw 700 Series gas valves.
Should this gas valve be installed or converted by a professional?
Yes. Gas valve installation and LP conversion should only be completed by a qualified HVAC or gas appliance technician.
Need Help With HVAC Parts or Installation?
Contact Advanced Service Company LLC for professional HVAC service, parts support, and installation assistance.
